Product thermal capacity: 1-4 t/h
Working pressure: 1.0-1.6 MPa
Available fuel: Natural gas, coke oven gas, biogas, diesel, heavy oil, light oil, residual oil, etc.
Available industries: Chemical, food, cigarettes and tobacco, textile, building materials, hospital, heating etc.
Email: zhulin@zozen.com
WNS Series 1 Ton Boiler Introduction
The WNS series 1 ton boiler is a skid-mounted boiler with an integrated design, where all auxiliary machines and accessories are integrated on a single frame. It features a compact structure and a rational layout, effectively reducing the footprint. The WNS series 1 ton boiler requires no installation; users only need to connect water, electricity, and gas, and it can be operational within a day, ready for immediate use. The unique design of the WNS series 1 ton boiler provides excellent mobility.
WNS Series 1 Ton Boiler Advantage
Integrated Design: The WNS series 1 ton boiler boasts an integrated design where all auxiliary components are consolidated on a single frame, ensuring a compact structure and efficient use of space.
Quick Installation: This boiler requires no assembly, with users only needing to connect water, electricity, and gas. Within a day, it can be fully operational, enabling rapid deployment and immediate use.
Enhanced Mobility: The unique design of the WNS series 1 ton boiler ensures excellent mobility, allowing for easy relocation and flexibility in various operational settings.
Installation without Inspection: No specific qualifications required, convenient and time-saving.
WNS Series 1 Ton BoilerSpecification
| Model | Rated steam capacity（t/h） | Rated working pressure（MPa） | Rated steam temperature（℃） | Maximum transport dimension (m)(L×W×H) |
| WNS1-1.0-Q(Y) | 1.0 | 1.0 | 184 | 5.00×2.25×2.50 |
| WNS1-1.25-Q(Y) | 1.0 | 1.25 | 194 | 5.00×2.25×2.50 |
| WNS1.5-1.0-Q(Y) | 1.5 | 1.0 | 184 | 4.50×2.25×2.50 |
| WNS1.5-1.25-Q(Y) | 1.5 | 1.25 | 194 | 4.50×2.25×2.50 |
| WNS2-1.0-Q(Y) | 2.0 | 1.0 | 184 | 7.50×2.25×2.50 |
| WNS2-1.25-Q(Y) | 2.0 | 1.25 | 194 | 7.50×2.25×2.50 |
| WNS3-1.0-Q(Y) | 3.0 | 1.0 | 184 | 8.50×2.25×2.50 |
| WNS3-1.25-Q(Y) | 3.0 | 1.25 | 194 | 8.50×2.25×2.50 |
| WNS4-1.25-Q(Y) | 4.0 | 1.25 | 194 | 10.50×2.25×2.50 |
| WNS4-1.6-Q(Y) | 4.0 | 1.6 | 204 | 10.50×2.25×2.50 |
