Product thermal capacity: 2-110 t/h
Working pressure: 1.25-5.3 MPa
Available fuel: Natural gas, coke oven gas, blast furnace gas, carbon black tail gas, biogas, diesel, heavy oil, light oil, crude oil, etc.
Available industries: Heat supplying, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc.
Email: zhulin@zozen.com
SZS Series Paper Industry Steam Boiler Introduction
The SZS series paper industry steam boiler offers multiple advantages such as compact structure, stable performance, energy efficiency, and environmental friendliness. As a water tube boiler, the SZS series features a double-drum design, ensuring reasonable structure and high combustion efficiency, which meets the paper industry’s demand for stable steam supply. With an impressive thermal efficiency of over 98%, the SZS series can significantly reduce energy consumption and save operational costs for paper enterprises. Additionally, the boiler ensures stable operation, providing uninterrupted steam supply during production processes, greatly enhancing the stability of production lines.
SZS Series Paper Industry Steam Boiler Advantage
SZS Series Paper Industry Steam Boiler Specification
| Model | Rated steam capacity (t/h) | Rated working pressure (MPa) | Rated steam temperature (℃) | Feed water temperature (℃) | Maximum transport dimension (m) |
| SZS2-2.5-Q(Y) | 2 | 2.5 | 225 | 20 | 4.75×2.65×2.91 |
| SZS4-2.5-Q(Y) | 4 | 2.5 | 225 | 20 | 6.25×2.96×3.11 |
| SZS6-1.25-Q(Y) | 6 | 1.25 | 194 | 20 | 6.85×3.36×3.38 |
| SZS6-1.6-Q(Y) | 6 | 1.6 | 204 | 20 | 6.85×3.36×3.38 |
| SZS6-2.5-Q(Y) | 6 | 2.5 | 225 | 20 | 6.85×3.36×3.38 |
| SZS10-1.25-Q(Y) | 10 | 1.25 | 194 | 104/20 | 7.95×3.65×3.65 |
| SZS10-1.6-Q(Y) | 10 | 1.6 | 204 | 104/20 | 7.95×3.65×3.65 |
| SZS10-2.5-Q(Y) | 10 | 2.5 | 225 | 104/20 | 7.95×3.65×3.65 |
| SZS15-1.25-Q(Y) | 15 | 1.25 | 194 | 104/20 | 8.80×3.76×3.65 |
| SZS15-1.6-Q(Y) | 15 | 1.6 | 204 | 104/20 | 8.80×3.76×3.65 |
| SZS15-2.5-Q(Y) | 15 | 2.5 | 225 | 104/20 | 8.80×3.76×3.65 |
| SZS20-1.25-Q(Y) | 20 | 1.25 | 194 | 104/20 | 8.80×3.96×3.90 |
| SZS20-1.6-Q(Y) | 20 | 1.6 | 204 | 104/20 | 8.80×3.96×3.90 |
| SZS20-2.5-Q(Y) | 20 | 2.5 | 225 | 104/20 | 8.80×3.96×3.90 |
| SZS25-1.25-Q(Y) | 25 | 1.25 | 194 | 104/20 | 9.60×3.96×3.90 |
| SZS25-1.6-Q(Y) | 25 | 1.6 | 204 | 104/20 | 9.60×3.96×3.90 |
| SZS25-2.5-Q(Y) | 25 | 2.5 | 225 | 104/20 | 9.60×3.96×3.90 |
| SZS30-1.25-Q(Y) | 30 | 1.25 | 194 | 104/20 | 10.70×4.40×4.20 |
| SZS30-1.6-Q(Y) | 30 | 1.6 | 204 | 104/20 | 10.70×4.40×4.20 |
| SZS30-2.5-Q(Y) | 30 | 2.5 | 225 | 104/20 | 10.70×4.40×4.20 |
| SZS35-1.25-Q(Y) | 35 | 1.25 | 194 | 104/20 | 11.5×4.40×4.20 |
| SZS35-1.6-Q(Y) | 35 | 1.6 | 204 | 104/20 | 11.5×4.40×4.20 |
| SZS35-2.5-Q(Y) | 35 | 2.5 | 225 | 104/20 | 11.5×4.40×4.20 |
| SZS40-1.25-Q(Y) | 40 | 1.25 | 194 | 104/20 | 11.7×4.40×4.20 |
| SZS40-1.6-Q(Y) | 40 | 1.6 | 204 | 104/20 | 11.7×4.40×4.20 |
| SZS40-2.5-Q(Y) | 40 | 2.5 | 225 | 104/20 | 11.7×4.40×4.20 |
| SZS50-1.25-Q(Y) | 50 | 1.25 | 194 | 104/20 | 12.32×3.25×4.06 |
| SZS50-1.6-Q(Y) | 50 | 1.6 | 204 | 104/20 | 12.32×3.25×4.06 |
| SZS50-2.5-Q(Y) | 50 | 2.5 | 225 | 104/20 | 12.32×3.25×4.06 |
| SZS65-1.25-Q(Y) | 65 | 1.25 | 194 | 104/20 | 12.00×1.50×1.80 |
| SZS65-1.6-Q(Y) | 65 | 1.6 | 204 | 104/20 | 12.00×1.50×1.80 |
| SZS65-2.5-Q(Y) | 65 | 2.5 | 225 | 104/20 | 12.00×1.50×1.80 |
| SZS75-1.25-Q(Y) | 75 | 1.25 | 194 | 104/20 | 12.00×1.50×1.80 |
| SZS75-1.6-Q(Y) | 75 | 1.6 | 204 | 104/20 | 12.00×1.50×1.80 |
| SZS75-2.5-Q(Y) | 75 | 2.5 | 225 | 104/20 | 12.00×1.50×1.80 |
| SZS100-1.25-Q(Y) | 100 | 1.25 | 194 | 104/20 | 13.00×1.50×1.80 |
| SZS100-1.6-Q(Y) | 100 | 1.6 | 204 | 104/20 | 13.00×1.50×1.80 |
| SZS100-2.5-Q(Y) | 100 | 2.5 | 225 | 104/20 | 13.00×1.50×1.80 |
| SZS110-1.25-Q(Y) | 110 | 1.25 | 194 | 104/20 | 13.00×1.50×1.80 |
| SZS110-1.6-Q(Y) | 110 | 1.6 | 204 | 104/20 | 13.00×1.50×1.80 |
| SZS110-2.5-Q(Y) | 110 | 2.5 | 225 | 104/20 | 13.00×1.50×1.80 |
