2 Ton WNS series steam boiler on the convective heat transfer of smoke district layout, spelling abandoned the traditional two, three, return “velocity” such as the design point of view, and adopted the “resistance” such as design and arrangement of the new ideas convective heat transfer surface. The steam boiler manufacturing in the furnace design broke through to determine the furnace flame diameter size of the diameter of the traditional design ideas, using the large corrugated furnace structure, greatly improve the radiation heat transfer area, reduce NOX emissions. The threaded flue gas pipe technology is applied in the convective heat exchanger zone, and the boiler efficiency is over 96.2%, which greatly improves the boiler efficiency.
The smoke box of 2 Ton low nitrogen steam boiler adopts double-sealed small smoke room structure to eliminate leakage of smoke, which is convenient for maintenance of users. Aluminum silicate fiber felt is used for insulation, with good insulation effect. As we have done a lot of work in combustion and heat transfer, we have adopted some new structures and technologies, which greatly reduce the volume of the product, reduce the room space and reduce the weight.
The combustion chamber of WNS series industrial boiler adopts corrugated furnace bile, which has good thermal expansion performance. The combustion chamber is equipped with explosion-proof door, and the furnace body is equipped with highly sensitive temperature, pressure and water level sensors. The controller consists of high reliability and multiple safety protection control system to ensure the safe operation of the boiler. Boiler water capacity, stable and reliable operation, high heating quality.
The boiler adopts the structure of large furnace and corrugated furnace, which increases the radiation heat transfer area and facilitates the full combustion of fuel. The fuzzy control technology based on artificial neural network and the world famous burner are applied to realize the automatic regulation of combustion according to the temperature, pressure and time, so that the boiler can run efficiently and economically under different conditions and reduce the consumption of fuel to the maximum extent.
WNS series steam boiler is equipped with industrial burners with good technical performance, and adopt advanced technologies such as automatic proportional combustion regulation, automatic feed water regulation, program start and stop, automatic operation, etc., and have automatic protection functions such as high and low water level alarm, extremely low water level, ultra-high steam pressure, flameout, etc. The boiler has the characteristics of compact structure, safe and reliable, simple operation, quick installation, less pollution, low noise and high efficiency. Welcome everyone to come to consult purchasing, ZOZEN Boilers will serve you wholeheartedly.
